Custom Gears & Shafts | Precision Power Transmission

Precision gears & shafts for power transmission — AGMA / DIN quality

Quality gradeAGMA 10–12 / DIN 5–7

Max diameterØ800 mm

Lead time2–4 weeks

MOQ10 pcs

Price$5–150

MOQ10 pcs

Lead time2-4 weeks

Request a Quote Talk to an Engineer

Upload your CAD for instant pricing · We respond within 24 hours · No obligation

Overview Specifications Capabilities Materials & Finishes Quality Applications FAQ Reviews (2)

Overview

Mechpart manufactures custom gears and shafts for demanding power-transmission applications — spur, helical, bevel and worm gears, splines, racks and precision shafts. With in-house hobbing, shaping and profile grinding we hold AGMA 10–12 / DIN 5–7 quality for quiet, high-load running.

Integrated carburizing, induction hardening and nitriding deliver the wear resistance gearboxes, robotics and automotive drivetrains demand, while full gear-analyzer inspection (profile, lead, pitch, runout) documents every batch. We also reverse-engineer and reproduce obsolete gears from samples or worn parts.

Technical specifications

Gear types	Spur, helical, bevel, worm, internal, racks, splines, sprockets
Quality grade	AGMA 10–12 / DIN class 5–7 (ground)
Module / DP	0.5–20 module (DP 1–48)
Max gear diameter	Ø800 mm; shafts up to 1,500 mm
Tooth finishing	Hobbing, shaping, grinding, honing, shaving
Heat treatment	Carburizing, induction hardening, nitriding, through-hardening
Inspection	Gear analyzer (profile, lead, pitch, runout), hardness, metallurgy
Volume	10–50,000+ pcs

Process capabilities

Gear grinding

Ground tooth flanks for AGMA 12 quality, quiet running and high load.

Hobbing & shaping

Efficient cutting of external/internal gears, splines and sprockets.

Shaft machining

Precision turning and grinding of shafts, keyways and bearing seats.

Heat-treat integration

In-line carburizing and induction hardening for wear resistance.

Materials & finishes

Materials

20CrMnTi / 8620 case-hardening steel 4140 / 4340 alloy steel 17-4PH stainlessBronze (worm gears)Cast ironPOM / PEEK (plastic gears)

All materials & properties →

Surface finishes

Ground flanksBlack oxidePhosphateZinc platingNitridePolished bearing seats

Quality & certifications

Incoming — material certification & spectrometer verification on every lot.
In-process — dimensional checks at each operation with calibrated instruments.
First article — full CMM report, FAIR / PPAP available on request.
Final — visual, dimensional & surface-finish inspection with documentation.

ISO 9001:2015IATF 16949AS9100DISO 14001ISO 13485

Typical applications

Industrial gearboxes

Reducers, increasers and drive trains for machinery.

Robotics

Precision reduction gears and harmonic-drive components.

Automotive

Transmission, differential and steering gears.

Wind & energy

Yaw and pitch drive gears, gearbox internals.

Frequently asked

What gear quality can you achieve?

Up to AGMA 12 / DIN 5 with profile grinding; AGMA 8–10 as-hobbed.

Can you reverse-engineer an existing gear?

Yes — we measure tooth geometry and reproduce gears from samples or worn parts.

Do you harden and balance shafts?

Yes — induction/through-hardening plus dynamic balancing on request.

What lead time for custom gears?

Typically 2–4 weeks depending on grinding and heat-treat requirements.

Customer reviews (2)

5.0/ 5 · 2 verified

★★★★★

Precision ground, quiet running

Helical gears for our gearbox came in at AGMA class 10. Hardness and profile both verified. Excellent work.

T Thomas BergDrivetrain Engineer, Oslo Marine
